Medical ARM Mini PC G4-RK3566
Model:
G4-3566
Quad Core 64 bit Cortex-A55 Processor
With 2GB RAM，16GB Flash onboard
Smallest Size: 16*W 13*H 5.5cm
Support 2.4GHz / 5GHz dual-band WiFi
Support 7x24 working time
Support Android11/Ubuntu 20.04/Debian10/Centos8
Quad Core 64 bit Cortex-A55 Processor
With 2GB RAM，16GB Flash onboard
Smallest Size: 16*W 13*H 5.5cm
Support 2.4GHz / 5GHz dual-band WiFi
Support 7x24 working time
Support Android11/Ubuntu 20.04/Debian10/Centos8
The Slim Mini PC G4-RK3566, with CPU RK3566 and compatible with Android 11, Ubuntu 20.04, Debian 10, and Centos 8, can be utilized in the medical queuing system as follows: Connect it to the display for presenting queuing details. Install the appropriate queuing software based on the compatible operating system. Ensure stable network connection for real-time data update. Use input devices for convenient operation and control.
-
Part No.G4C-RK3399
-
-
Processor
CPU
RK3399 (28 NM HKMG procedure)
Core number
6 cores 64 bit
Frequency
Dual-core Cortex-A72 up to 2.0GHz, Dual-core Cortex-A53 up to 1.5GHz
Max Turbo Frequency
2.0GHz
Chipset
ARM
-
GPU
GPU
Mail-T860 MP4 quad-core GPU Support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, support AFBC (frame buffer compression)
-
Memory
Memory
LPDDR4 1G/(4G MAX)
-
Storage
EMMC
16G optional
Expansion
TF card
-
I/O Interface
Front
2*LAN(WAN+LAN), Type-C 5V input
Rear
2*USB3.0，TF Card Slot
-
Network
Network
Support Ethernet 10/100/1000Mbps, support Ethernet TX/RX:935Mbps
-
Power adapter
Power adapter
Type-C 5V input
-
Operating System
Operating System
OpenWRT or CentOS
-
Physical
Dimension
65*65mm
Weight(Net)
0.3kg
Color
Blue
Cooling Method
Fanless Passive Cooling
Certification
CE,FCC,ROHS,ISO
-
Environment
Operating Temperature
-10~60 ℃
Storage Temperature
-10~60 ℃
Operation Humidity
0~95% (No Condensation)
Storage Humidity
0~95% (No Condensation)
-
CPU
G4C-RK3399
RK3399 (28 NM HKMG procedure)
-
Core number
G4C-RK3399
6 cores 64 bit
-
Frequency
G4C-RK3399
Dual-core Cortex-A72 up to 2.0GHz, Dual-core Cortex-A53 up to 1.5GHz
-
Max Turbo Frequency
G4C-RK3399
2.0GHz
-
Chipset
G4C-RK3399
ARM
-
GPU
G4C-RK3399
Mail-T860 MP4 quad-core GPU Support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, support AFBC (frame buffer compression)
-
Memory
G4C-RK3399
LPDDR4 1G/(4G MAX)
-
EMMC
G4C-RK3399
16G optional
-
Expansion
G4C-RK3399
TF card
-
Front
G4C-RK3399
2*LAN(WAN+LAN), Type-C 5V input
-
Rear
G4C-RK3399
2*USB3.0，TF Card Slot
-
Network
G4C-RK3399
Support Ethernet 10/100/1000Mbps, support Ethernet TX/RX:935Mbps
-
Power adapter
G4C-RK3399
Type-C 5V input
-
Operating System
G4C-RK3399
OpenWRT or CentOS
-
Dimension
G4C-RK3399
65*65mm
-
Weight(Net)
G4C-RK3399
0.3kg
-
Color
G4C-RK3399
Blue
-
Cooling Method
G4C-RK3399
Fanless Passive Cooling
-
Certification
G4C-RK3399
CE,FCC,ROHS,ISO
-
Operating Temperature
G4C-RK3399
-10~60 ℃
-
Storage Temperature
G4C-RK3399
-10~60 ℃
-
Operation Humidity
G4C-RK3399
0~95% (No Condensation)
-
Storage Humidity
G4C-RK3399
0~95% (No Condensation)
