AIO238 Intel Core Ultra 5 135H

Model:

AK-2308
  • Intel Core i3/i5/i7 11th-14th(6 cores, 12 threads,  with  Intel UHD Graphics)

  • High speed RAM DDR4 up to 32GB, 512GB M.2 SATA SSD storage

  • Built-in 2.4G+5G Dual-Band WiFi

  • Windows 10/11 Pro

  • Applied in Office, Education and Family, etc,.

The AK-2308 desktop computer combines robust performance with elegant design, featuring a sophisticated chassis crafted from sleek silver aluminum alloy that ensures durability, efficient heat dissipation, and a premium aesthetic. Equipped with powerful 11th to 14th Generation Intel Core i3, i5, or i7 processors, it delivers seamless multitasking for diverse environments including office productivity, educational applications, and family entertainment. This versatile system offers extensive connectivity through four USB ports and built-in Wi-Fi, supports all versions of the Windows operating system for maximum flexibility, and operates globally with its energy-efficient 110V~220V (120W max) universal power supply – all housed within its modern, lightweight aluminum frame designed for reliability in any setting.

  • Part No.
    AK-2308-i3/i5/i7 11th-14th
  • Processor

    CPU

    Intel Core i3/i5/i7 11th-14th, 6 Cores / 12 Threads

    Cache

    12MB

    Chipset

    Intel 400/500/600/700 Series (Varies by CPU)

  • Memory

    Technology

    2*SO-DIMM DDR4L

    Max. Capacity

    32GB

  • Storage

    M.2 SATA

    SSD 128GB/256GB/512GB

    SATA

    HDD 500GB/1TB/2TB (Optional)

  • Graphics

    Graphics

    Intel UHD Graphics(Varies by CPU)

  • Speaker

    Speaker

    Built-in 2 Channel stereo

  • Network

    LAN

    10/100/1000Mbps Adaptive RTL 8111H

    Wireless

    802.11b/g/n 2.4G 1T/1R WiFi with Bluetooth V2.1+EDR/Bluetooth 3.0+HS/4.0 or IEEE 802.11a/b/g/n/ac Wireless LAN 1T1R and Bluetooth 4.2 Combo Module

  • I/O Interface

    Side

    2× USB 2.0、2× USB 3.0、1× RJ45、1× HDMI、1× DP or 1× VGA or 1× COM、1×Type-C、Audio IN/OUT、

  • Extendable

    Module

    Built-in 2.4G+5G Dual-Band WiFi module

  • Power

    Working Voltage

    110V~220V 120W AC-DC (Built-in)

  • Operating System

    Windows 10/11 Pro

  • Physical

    Dimension

    23.8 inch

    Weight(Net)

    5.46 kg

    Color

    Silver

    Cooling Method

    Active cooling

    Mounting Options

    Standing Base

    Certification

    CE, FCC, ROHS, ISO, UL

  • Environment

    Operating Temperature

    0~60 ℃

    Storage Temperature

    -20~75 ℃

    Operation Humidity

    0~95% (No Condensation)

    Storage Humidity

    0~95% (No Condensation)

Processor
  • CPU

    AK-2308-i3/i5/i7 11th-14th

    Intel Core i3/i5/i7 11th-14th, 6 Cores / 12 Threads

  • Cache

    AK-2308-i3/i5/i7 11th-14th

    12MB

  • Chipset

    AK-2308-i3/i5/i7 11th-14th

    Intel 400/500/600/700 Series (Varies by CPU)

Memory
  • Technology

    AK-2308-i3/i5/i7 11th-14th

    2*SO-DIMM DDR4L

  • Max. Capacity

    AK-2308-i3/i5/i7 11th-14th

    32GB

Storage
  • M.2 SATA

    AK-2308-i3/i5/i7 11th-14th

    SSD 128GB/256GB/512GB

  • SATA

    AK-2308-i3/i5/i7 11th-14th

    HDD 500GB/1TB/2TB (Optional)

Graphics
  • Graphics

    AK-2308-i3/i5/i7 11th-14th

    Intel UHD Graphics(Varies by CPU)

Speaker
  • Speaker

    AK-2308-i3/i5/i7 11th-14th

    Built-in 2 Channel stereo

Network
  • LAN

    AK-2308-i3/i5/i7 11th-14th

    10/100/1000Mbps Adaptive RTL 8111H

  • Wireless

    AK-2308-i3/i5/i7 11th-14th

    802.11b/g/n 2.4G 1T/1R WiFi with Bluetooth V2.1+EDR/Bluetooth 3.0+HS/4.0 or IEEE 802.11a/b/g/n/ac Wireless LAN 1T1R and Bluetooth 4.2 Combo Module

I/O Interface
  • Side

    AK-2308-i3/i5/i7 11th-14th

    2× USB 2.0、2× USB 3.0、1× RJ45、1× HDMI、1× DP or 1× VGA or 1× COM、1×Type-C、Audio IN/OUT、

Extendable
  • Module

    AK-2308-i3/i5/i7 11th-14th

    Built-in 2.4G+5G Dual-Band WiFi module

Power
  • Working Voltage

    AK-2308-i3/i5/i7 11th-14th

    110V~220V 120W AC-DC (Built-in)

Operating System
  • AK-2308-i3/i5/i7 11th-14th

    Windows 10/11 Pro

Physical
  • Dimension

    AK-2308-i3/i5/i7 11th-14th

    23.8 inch

  • Weight(Net)

    AK-2308-i3/i5/i7 11th-14th

    5.46 kg

  • Color

    AK-2308-i3/i5/i7 11th-14th

    Silver

  • Cooling Method

    AK-2308-i3/i5/i7 11th-14th

    Active cooling

  • Mounting Options

    AK-2308-i3/i5/i7 11th-14th

    Standing Base

  • Certification

    AK-2308-i3/i5/i7 11th-14th

    CE, FCC, ROHS, ISO, UL

Environment
  • Operating Temperature

    AK-2308-i3/i5/i7 11th-14th

    0~60 ℃

  • Storage Temperature

    AK-2308-i3/i5/i7 11th-14th

    -20~75 ℃

  • Operation Humidity

    AK-2308-i3/i5/i7 11th-14th

    0~95% (No Condensation)

  • Storage Humidity

    AK-2308-i3/i5/i7 11th-14th

    0~95% (No Condensation)
