G4 Slim Mini PC
Model: G4
● Quad Core 64 bit Cortex-A55 Processor
● With 2GB RAM, 16GB Flash onboard
● Smallest Size: L 65*W 70*H 25 mm
● Support 2.4GHz / 5GHz dual-band WiFi
● Support 7x24 working time
● Support Android11/Ubuntu 20.04/Debian10/Centos8.3
Data Sheet 1
Send InquiryG4 Slim Mini PC is with Quad Core 64 bit Cortex-A55 Processor, 2GB RAM, 16GB flash, or 4G+32/64G eMMC, L 65*W 70*H 25 mm, support Android11/Ubuntu 20.04/Debian10/Centos8.3, 1x LAN, 1xHDMI, 4x USB, 1x Type-C DC, Audio.
-
Part No.G4-RK3566
-
-
Processor
CPU
Quad Core 64bit Cortex-A55 Processor, 4 Cores / 4 Threads
Frequency
1.8GHz
GPU
ARM G52 2EE; Support OpenGL ES 1.1/2.0/3.2，OpenCL 2.0，Vulkan 1.1; Support 2D hardware acceleration
VPU
Support 4K 60fps H.265/H.264/VP9 video decode; Support 1080P 60fps H.265/H.264 video encode; Support 8M ISP，HDR
-
Memory
Technology
DDR3L 1600 MHz
Max. Capacity
2GB
-
Storage
MSATA
Onboard 16GB EMMC
SATA
NONE
-
Network
10/100/1000Mbps Adaptive
-
I/O Interface
Front
1*USB2.0、1*USB3.0 、1*Power ON/OFF
Rear
2*USB2.0, 1*HDMI、1*RJ45、1*Type-c DC 、1*MIC-IN&LINE-OUT
-
Power
Input Voltage
AC100-240V. 50-60Hz DC
Power Output
DC 5V 2A
-
Operating System
OS
Android11、Ubuntu20.04、Debian10、Centos8.3
Boot Mode
Auto-power-on
-
Physical
Dimension
L 65*W 70*H 25 mm
Weight(Net)
0.4kg
Color
Black
Cooling Method
Fanless Passive Cooling
Mounting Options
Vertical Stand
Certification
CE, FCC, ROHS, ISO
-
CPU
G4-RK3566
Quad Core 64bit Cortex-A55 Processor, 4 Cores / 4 Threads
-
Frequency
G4-RK3566
1.8GHz
-
GPU
G4-RK3566
ARM G52 2EE; Support OpenGL ES 1.1/2.0/3.2，OpenCL 2.0，Vulkan 1.1; Support 2D hardware acceleration
-
VPU
G4-RK3566
Support 4K 60fps H.265/H.264/VP9 video decode; Support 1080P 60fps H.265/H.264 video encode; Support 8M ISP，HDR
-
Technology
G4-RK3566
DDR3L 1600 MHz
-
Max. Capacity
G4-RK3566
2GB
-
MSATA
G4-RK3566
Onboard 16GB EMMC
-
SATA
G4-RK3566
NONE
-
G4-RK3566
10/100/1000Mbps Adaptive
-
Front
G4-RK3566
1*USB2.0、1*USB3.0 、1*Power ON/OFF
-
Rear
G4-RK3566
2*USB2.0, 1*HDMI、1*RJ45、1*Type-c DC 、1*MIC-IN&LINE-OUT
-
Input Voltage
G4-RK3566
AC100-240V. 50-60Hz DC
-
Power Output
G4-RK3566
DC 5V 2A
-
OS
G4-RK3566
Android11、Ubuntu20.04、Debian10、Centos8.3
-
Boot Mode
G4-RK3566
Auto-power-on
-
Dimension
G4-RK3566
L 65*W 70*H 25 mm
-
Weight(Net)
G4-RK3566
0.4kg
-
Color
G4-RK3566
Black
-
Cooling Method
G4-RK3566
Fanless Passive Cooling
-
Mounting Options
G4-RK3566
Vertical Stand
-
Certification
G4-RK3566
CE, FCC, ROHS, ISO
