Part No.AIMB-G401
-
-
Form Factor
NANO-ITX
-
Hardware Specification
CPU
RK3399 (28 NM HKMG procedure)
ARM 6-core 64-bit processor, Frequency up to 2.0GHz
Based on big. LITTLE large and small core architecture, dual-core Cortex-A72 (large core) + quad-core Cortex-A53 (small core)
GPU
Mail-T860 MP4 Quad-core GPU
Support OpenGL ES1.1/2.0/3.0/3.1,OpenVG1.1,OpenCL,DX11
support AFBC (frame buffer compression)
Hardware Acceleration
Support AES encryption and decryption hardware acceleration
GPIO
10
RTC
2Pin 1.25mm
RAM
LPDDR4 1G/(4G MAX)
Built-in storage capacity
TF Card expansion ky
EMMC
NC, 128GB MAX
Ethernet
Support Ethernet 10/100/1000Mbps
TX/RX:935Mbps
USB
2*USB-3.0
Button
1*Power button, 1*Programming button (not used yet)
Power Adapter
Type-c 5V input
Size
65*65mm
-
AIMB-G401
NANO-ITX
-
CPU
AIMB-G401
RK3399 (28 NM HKMG procedure)
-
AIMB-G401
ARM 6-core 64-bit processor, Frequency up to 2.0GHz
-
AIMB-G401
Based on big. LITTLE large and small core architecture, dual-core Cortex-A72 (large core) + quad-core Cortex-A53 (small core)
-
GPU
AIMB-G401
Mail-T860 MP4 Quad-core GPU
-
AIMB-G401
Support OpenGL ES1.1/2.0/3.0/3.1,OpenVG1.1,OpenCL,DX11
-
AIMB-G401
support AFBC (frame buffer compression)
-
Hardware Acceleration
AIMB-G401
Support AES encryption and decryption hardware acceleration
-
GPIO
AIMB-G401
10
-
RTC
AIMB-G401
2Pin 1.25mm
-
RAM
AIMB-G401
LPDDR4 1G/(4G MAX)
-
Built-in storage capacity
AIMB-G401
TF Card expansion ky
-
EMMC
AIMB-G401
NC, 128GB MAX
-
Ethernet
AIMB-G401
Support Ethernet 10/100/1000Mbps
-
AIMB-G401
TX/RX:935Mbps
-
USB
AIMB-G401
2*USB-3.0
-
Button
AIMB-G401
1*Power button, 1*Programming button (not used yet)
-
Power Adapter
AIMB-G401
Type-c 5V input
-
Size
AIMB-G401
65*65mm
