NANO-ITX AIMB-K303

Model: AIMB-K303

● 10th Gen Intel® Core i3, 15W TDP

● 2x 204-pin SO-DIMM up to 64 GB, DDR4L 2666MHz SDRAM

● Triple display: 2HDMI,1 DP, Intel Intel UHD Graphics Gen10

● Realtek ALC887

● 2*Ethernet 10/100/1000 Mbps LAN

● 1 MINI PCIE, M.2 E Key, SIM Slot, 1 SATA, 1 mSATA

● 4 USB 3.0, 2 USB 2.0, 4 COM, 1 PCIE-GPIO

● Support TPM Module

● 3xRS-232, 1xRS-232/485

Intel core i3-10110u NANO-ITX with 2 HDMI, 1 DP, 6 USB, 4 COM, 2 LAN

Product Specification
Form Factor
  • AIMB-K303

    NANO-ITX

Processor
  • CPU

    AIMB-K303

    Intel Core i3-10110u

  • BIOS

    AIMB-K303

    AMI BIOS

  • Core Number

    AIMB-K303

    2

  • CPU TDP

    AIMB-K303

    15W

  • Frequency

    AIMB-K303

    2.1GHz~4.1GHz

  • L3 Cache

    AIMB-K303

    4MB

Memory
  • Technology

    AIMB-K303

    DDR4 2666Mhz

  • Max.Capacity

    AIMB-K303

    SO-DIMM up to 16GB

  • Socket

    AIMB-K303

    2*260 PIN SO-DIMM

Display
  • Controller

    AIMB-K303

    Intel UHD Graphics Gen10

  • Video Interface

    AIMB-K303

    2*HDMI

  • DP

    AIMB-K303

    1*DP

  • Multiple Display

    AIMB-K303

    Triple

Expansion
  • Slot Type

    AIMB-K303

    2

  • PCI Express

    AIMB-K303

    1*MINI PCIE+1*M.2 E key Type2230 for WIFI&BT(PCIe+USB)

Ethernet
  • Speed

    AIMB-K303

    10/100/1000 Mbps

  • Controller

    AIMB-K303

    Realtek 8111G

  • Connector

    AIMB-K303

    1*RJ45

Audio
  • Audio Interface

    AIMB-K303

    HD Audio

  • CODEC

    AIMB-K303

    Realtek ALC887

  • Connector

    AIMB-K303

    2(HP_OUT/ MIC_IN)

WatchDog Timer
  • AIMB-K303

    NO

I/O
  • USB

    AIMB-K303

    4*USB2.0, 4*USB3.0, 1*4PIN USB2.0

  • GPIO

    AIMB-K303

    1*PCIE-10PIN

  • COM Port

    AIMB-K303

    4 (3xRS-232, 1xRS-232/485)

  • TPM

    AIMB-K303

    1*14-1Pin TPM

  • SIM

    AIMB-K303

    1*SIM

  • Type-C

    AIMB-K303

    1*Type-C

Storage
  • M.2

    AIMB-K303

    1*M.2 M key Type2280 For SSD(SATA/NvMe)

  • SATA

    AIMB-K303

    1*SATA, support 2.5inch sata Interface

Power
  • Power type

    AIMB-K303

    DC 12V

  • Connector

    AIMB-K303

    DC jack

  • Power Adaptor

    AIMB-K303

    Yes

Environment
  • Non-Operational Temperature

    AIMB-K303

    "-10℃~60℃"

  • Operational Temperature

    AIMB-K303

    "-10℃~60℃"

Physical
  • Dimension

    AIMB-K303

    120mmX120mm

  • Weight

    AIMB-K303

    153g

  • Construction

    AIMB-K303

    with fanless design or cooling fan

Operating System
  • Microsoft Windows

    AIMB-K303

    Yes

  • Linux

    AIMB-K303

    Yes
