Part No.AIMB-K305
-
-
Part Number
Form Factor
NANO-ITX
-
Processor
CPU
Intel Core I3-6006U
BIOS
AMI BIOS
Core Number
2
CPU TDP
15W
Frequency
2.0GHz
L3 Cache
3MB
-
Memory
Technology
DDR4 2400MHz
Max.Capacity
SO-DIMM up to 16GB
Socket
2*260 PIN SO-DIMM
-
Display
Controller
Intel HD Graphics 520
Video Interface
3*HDMI
-
Expansion
Slot Type
2
PCI Express
M.2 E key Type2230 for WIFI&BT(PCIe+USB)) M.2 E key Type2280 for SATA or 3G/4G
-
Ethernet
Speed
10/100/1000/2500 Mbps
Controller
intel I225-v
Connector
2*RJ45
-
Audio
Audio Interface
HD Audio
CODEC
ALC887
-
WatchDog Timer
WatchDog Timer
NO
-
I/O
USB
4*USB3.0, 4*USB2.0
GPIO
1*GPIO 10Pin
COM Port
6*COM
-
Storage
M-SATA
1*MINI PCIE Msata for SSD
SATA
1*SATA,support 2.5inch sata Interface
-
Power
Power type
DC 12V
Connector
DC jack
Power Adaptor
Yes
-
Environment
Non-Operational Temperature
"-10℃~60℃"
Operational Temperature
"-10℃~60℃"
-
Physical
Dimension
170mmX120mm
Weight
33g
Construction
with fanless design
-
Operating System
Microsoft Windows
Yes
Linux
Yes
-
