Part No.AIMB-K604
-
-
Form Factor
NANO-ITX
-
Processor
CPU
Intel Celeron J4125
BIOS
AMI BIOS
Core Number
4
CPU TDP
10W
Frequency
2.0GHz~2.7GHz
L3 Cache
4MB
-
Memory
Technology
DDR4 2666Mhz
Max.Capacity
SO-DIMM up to 16GB
Socket
1*260 PIN SO-DIMM
-
Display
Controller
Intel UHD Graphics 600
Video Interface
2*HDMI
DP
1*DP
Multiple Display
Triple
-
Expansion
Slot Type
1
PCI Express
1 (colay MINI PCIE)
-
Ethernet
Speed
10/100/1000/2500 Mbps
Controller
Intel I225
Connector
2*RJ45
-
Audio
Audio Interface
HD Audio
CODEC
Realtek ALC662
Connector
2(HP_OUT/ MIC_IN)
-
WatchDog Timer
Yes
-
I/O
USB
3*USB2.0, 3*USB3.0
GPIO
1*PCIE-10PIN
COM Port
2*20PIN COM
TPM
1*14-1Pin TPM
-
Storage
M-SATA
1*M.2 M key Type2280 For SSD (SATA/NvMe)
SATA
1*SATA, support 2.5 inch sata Interface
-
Power
Power type
DC 12V
Connector
DC jack
Power Adaptor
Yes
-
Environment
Non-Operational Temperature
"-10℃~60℃"
Operational Temperature
"-10℃~60℃"
-
Physical
Dimension
120mmX120mm
Weight
140g
Construction
with fanless design or cooling fan
-
Operating System
Microsoft Windows
Yes
Linux
Yes
-
