Part No.AIMB-X701
-
-
Form Factor
NANO-ITX
-
Hardware Specification
CPU
RK3288, Quad-core Cortex-A17, main frequency 1.8Ghz*4
Memory
DDR3 2GB (up to 4GB)
Storage
Onboard 16GB EMMC(32GB optional)
TF Card extendable
OS
Android7.1/Ubuntu18.04
Display
1*eDP.Support 3.3V/5V/12V Power Supply
1*LVDS(single output,dual 6bit,8bit,dual 10bit),Support 7'' screen and above,support 1080P 60Hz output,support 3.3V/5V/12V power supply
1*HDMI output,support 1080P/4K 60Hz output
Onboard Backlight
Optional 3.3V/5V/12V
Network
RJ45 Gigabit Ethernet
Optional wifi module,support 2.4G &5G dual-band wifi
Optional bluetooth
Audio
1*MIC
Power Supply
Input：AC100-240V.50-60HZ
Output： DC12V 2A~5A（Depends on screen）
Button
1*burne
RTC
COMS for RTC
Support Automatic Power Up
USB
4* USB(one of USB is OTG)
Dimension
125mm *80mm
-
Software Specification
OS
Android7.1OS/Ubuntu18.04/Debian9
Video
Support video format: H.265/H.264/VP9/MAV/ WMV/AVS/H.263/MPEG4 1080P/2160P
Support multi-view video decoding
Support JPG/PNG
Default Application Software
Calculator, Browser, Calendar, Settings, Clock, Video Player, Search, Explorer
-
AIMB-X701
NANO-ITX
-
CPU
AIMB-X701
RK3288, Quad-core Cortex-A17, main frequency 1.8Ghz*4
-
Memory
AIMB-X701
DDR3 2GB (up to 4GB)
-
Storage
AIMB-X701
Onboard 16GB EMMC(32GB optional)
-
AIMB-X701
TF Card extendable
-
OS
AIMB-X701
Android7.1/Ubuntu18.04
-
Display
AIMB-X701
1*eDP.Support 3.3V/5V/12V Power Supply
-
AIMB-X701
1*LVDS(single output,dual 6bit,8bit,dual 10bit),Support 7'' screen and above,support 1080P 60Hz output,support 3.3V/5V/12V power supply
-
AIMB-X701
1*HDMI output,support 1080P/4K 60Hz output
-
Onboard Backlight
AIMB-X701
Optional 3.3V/5V/12V
-
Network
AIMB-X701
RJ45 Gigabit Ethernet
-
AIMB-X701
Optional wifi module,support 2.4G &5G dual-band wifi
-
AIMB-X701
Optional bluetooth
-
Audio
AIMB-X701
1*MIC
-
Power Supply
AIMB-X701
Input：AC100-240V.50-60HZ
-
AIMB-X701
Output： DC12V 2A~5A（Depends on screen）
-
Button
AIMB-X701
1*burne
-
RTC
AIMB-X701
COMS for RTC
-
AIMB-X701
Support Automatic Power Up
-
USB
AIMB-X701
4* USB(one of USB is OTG)
-
Dimension
AIMB-X701
125mm *80mm
-
OS
AIMB-X701
Android7.1OS/Ubuntu18.04/Debian9
-
Video
AIMB-X701
Support video format: H.265/H.264/VP9/MAV/ WMV/AVS/H.263/MPEG4 1080P/2160P
-
AIMB-X701
Support multi-view video decoding
-
AIMB-X701
Support JPG/PNG
-
Default Application Software
AIMB-X701
Calculator, Browser, Calendar, Settings, Clock, Video Player, Search, Explorer
