K6-F13G Windows Industrial PC

Model: K6-F13G

● Fanless and rugged design

● 1 RJ45 COM

● Support SIM and TF card

● VGA+HDMI port

● 6 USB port (4xUSB3.0, 2xUSB2.0)

● Extendable RAM,up to 8GB

● Extendable SSD,up to 512GB

● Windows10/Linux operating system


K6-F13G is a small designed and fanless PC powered by Intel celeron processor. It comes with 1 COM port and 1 LAN port, with SIM and TF card slots, 6USB port,VGA and HDMI display port. It works as a POS PC as well as small server with Windows 10 or Linux OS installed. The rugged and full aluminum housing makes it good for some wide range applications, such as factory, warehouse, supermarket, restaurant, bank, school etc.

Specification K6-F13G
Processor
  • CPU

    K6-F13G-N2840

    Intel Celeron N2840

  • Core Number

    K6-F13G-N2840

    2 Cores / 2 Threads

  • Frequency

    K6-F13G-N2840

    2.16GHz

  • Max Turbo Frequency

    K6-F13G-N2840

    2.16GHz

  • Chipset

    K6-F13G-N2840

    Bay Trail

Memory
  • Technology

    K6-F13G-N2840

    1*DDR3L slot

  • Max. Capacity

    K6-F13G-N2840

    8GB

Storage
  • MSATA

    K6-F13G-N2840

    SSD 16GB/32GB/64GB/128GB/256GB/512GB

  • SATA

    K6-F13G-N2840

    Optional HDD

Graphics
  • K6-F13G-N2840

    Intel HD Graphics

Audio
  • K6-F13G-N2840

    HD Audio realtek ALC 662

Network
  • K6-F13G-N2840

    10/100/1000Mbps Adaptive, RTL 8111F

I/O Interface
  • Front

    K6-F13G-N2840

    DC12V Input, HDMI+VGA, 2*USB2.0, 1*RJ45,1*COM

  • Rear

    K6-F13G-N2840

    2*USB3.0, 2*USB2.0,1*SIM slot,1*TF slot, MIC, SPK

Extendable
  • I/O

    K6-F13G-N2840

    4*USB2.0、2*USB3.0、HDMI+VGA、1*RJ45、1*COM、1*SIM slot、1*TF slot、1*DC、1*MIC-IN、1*LINE-OUT 1*FP、1*JP3、2~4*COM、1*GPIO

  • Module

    K6-F13G-N2840

    WIFI+Bluetooth Module (M.2 PCIE)

Power
  • Input

    K6-F13G-N2840

    AC100-240V.50-60HZ DC

  • Output

    K6-F13G-N2840

    12V-3A

Operating System
  • K6-F13G-N2840

    Windows/Linux

Physical
  • Dimension

    K6-F13G-N2840

    L 133.8mm*W 126.6mm*H 36.5mm

  • Weight(Net)

    K6-F13G-N2840

    0.6KG

  • Color

    K6-F13G-N2840

    Black

  • Cooling Method

    K6-F13G-N2840

    Fanless Passive Cooling

  • Mounting Options

    K6-F13G-N2840

    Desk/ Wall Mount/Embedded/ DIN Rail

  • Certification

    K6-F13G-N2840

    CE,FCC,ROHS,ISO

Environment
  • Operating Temperature

    K6-F13G-N2840

    -10~60 ℃

  • Storage Temperature

    K6-F13G-N2840

    -10~60 ℃

  • Operation Humidity

    K6-F13G-N2840

    0~95% (No Condensation)

  • Storage Humidity

    K6-F13G-N2840

    0~95% (No Condensation)
