K6-F1 Mini Embedded PC
Model: K6-F1-N3160
● Small, thin, fanless & compact housing design
● Energy-saving, only 6W, with stable 24/7 performance
● Intel quad core quad threads processor
● Graphics Intel® HD Graphics 400
● 2 Gigabit Ethernet ports
● 4 USB3.0 and 1 Type-C ports
● Dual display VGA and HDMI
The Fanless Mini PC K6-F1 is an impressive computing solution tailored for space-constrained environments. ShareVDI fanless embedded computer’s compact design and energy-efficient operation, consuming only 6W, allow it to run continuously 24/7. The ShareVDI K6-F1 embedded PC fanless is an ideal choice for energy-conscious applications.
Powered by a quad-core Intel CPU and equipped with Intel® HD Graphics 400, this fanless embedded box PC delivers reliable processing power and respectable graphics performance. ShareVDI fanless embedded computer K6-F1 features two Gigabit network ports for seamless connectivity and includes four USB 3.0 ports alongside one Type-C port for extensive peripheral support. The VGA and HDMI display interfaces provide flexibility for connecting to various displays.
The K6-F1 fanless industrial PC excels in expandability, supporting both embedded and wall-mounted installation methods and enhancing deployment versatility. Whether used for industrial control, digital signage, or other applications, the ShareVDI fanless embedded box PC combines a compact size, low power consumption, powerful hardware, and excellent expandability, making the K6-F1 fanless rugged PC a reliable choice for a wide range of scenarios.
-
Part No.K6-F1-N3160
-
-
Processor
CPU
Intel Celeron N3160, 4 Cores / 4 Threads
Frequency
1.6GHz
Max Turbo Frequency
2.24GHz
Cache
2MB L2 Cache
Chipset
Products formerly Braswell
-
Memory
Technology
1*DDR3L slot
Max. Capacity
8GB
-
Storage
mSATA
SSD 32GB/64GB/128GB/256GB/512GB
SATA
Not Support HDD
-
Graphics
Graphics
Intel® HD Graphics 400
-
Audio
Audio
HD Audio Realtek ALC 897
-
Network
LAN
2*10/100/1000MbpsAdaptive, RTL8111F
Wireless
802.11b/g/n 2.4G 1T/1R WiFi with Bluetooth V2.1+EDR/Bluetooth 3.0+HS/4.0 or IEEE 802.11a/b/g/n/ac Wireless LAN 1T1R and Bluetooth 4.2 Combo Module
-
I/O Interface
Front
Power ON/OFF, 1*RS232 COM, 1*MIC& SPK, 4*USB3.0, 1*Type-C
Rear
1*DC 12V, 2*LAN, 1*Reset, 1*VGA, 1*HDMI
-
Extendable
I/O Ports
1 * FP 8PIN, 1 * TPM 2.0 pin (12-1) , 4 * COM1 pin (RS232) , 1 * TPM pin 14PIN, 1 * CPU 3PIN block, 1 * SATA1 block, 1 * Sata pin block, 1 * BATCON1
Module
WIFI+Bluetooth Module (M.2 PCIE)
-
Power
Input
AC100-240V. 50-60Hz DC
Output
12V-3A
-
Operating System
Windows/Linux
-
Physical
Dimension
L 106.4mm*W 159.8mm*H 32.5mm
Weight(Net)
0.6KG
Color
Black
Cooling Method
Fanless Passive Cooling
Mounting Options
Dedicated bracket; Support VESA bracket or DIN bracket
Certification
CE, FCC, ROHS, ISO, UL
-
Environment
Operating Temperature
-10~60 ℃
Storage Temperature
-15~60 ℃
Operation Humidity
5~95% (No Condensation)
Storage Humidity
5~95% (No Condensation)
-
CPU
K6-F1-N3160
Intel Celeron N3160, 4 Cores / 4 Threads
-
Frequency
K6-F1-N3160
1.6GHz
-
Max Turbo Frequency
K6-F1-N3160
2.24GHz
-
Cache
K6-F1-N3160
2MB L2 Cache
-
Chipset
K6-F1-N3160
Products formerly Braswell
-
Technology
K6-F1-N3160
1*DDR3L slot
-
Max. Capacity
K6-F1-N3160
8GB
-
mSATA
K6-F1-N3160
SSD 32GB/64GB/128GB/256GB/512GB
-
SATA
K6-F1-N3160
Not Support HDD
-
Graphics
K6-F1-N3160
Intel® HD Graphics 400
-
Audio
K6-F1-N3160
HD Audio Realtek ALC 897
-
LAN
K6-F1-N3160
2*10/100/1000MbpsAdaptive, RTL8111F
-
Wireless
K6-F1-N3160
802.11b/g/n 2.4G 1T/1R WiFi with Bluetooth V2.1+EDR/Bluetooth 3.0+HS/4.0 or IEEE 802.11a/b/g/n/ac Wireless LAN 1T1R and Bluetooth 4.2 Combo Module
-
Front
K6-F1-N3160
Power ON/OFF, 1*RS232 COM, 1*MIC& SPK, 4*USB3.0, 1*Type-C
-
Rear
K6-F1-N3160
1*DC 12V, 2*LAN, 1*Reset, 1*VGA, 1*HDMI
-
I/O Ports
K6-F1-N3160
1 * FP 8PIN, 1 * TPM 2.0 pin (12-1) , 4 * COM1 pin (RS232) , 1 * TPM pin 14PIN, 1 * CPU 3PIN block, 1 * SATA1 block, 1 * Sata pin block, 1 * BATCON1
-
Module
K6-F1-N3160
WIFI+Bluetooth Module (M.2 PCIE)
-
Input
K6-F1-N3160
AC100-240V. 50-60Hz DC
-
Output
K6-F1-N3160
12V-3A
-
K6-F1-N3160
Windows/Linux
-
Dimension
K6-F1-N3160
L 106.4mm*W 159.8mm*H 32.5mm
-
Weight(Net)
K6-F1-N3160
0.6KG
-
Color
K6-F1-N3160
Black
-
Cooling Method
K6-F1-N3160
Fanless Passive Cooling
-
Mounting Options
K6-F1-N3160
Dedicated bracket; Support VESA bracket or DIN bracket
-
Certification
K6-F1-N3160
CE, FCC, ROHS, ISO, UL
-
Operating Temperature
K6-F1-N3160
-10~60 ℃
-
Storage Temperature
K6-F1-N3160
-15~60 ℃
-
Operation Humidity
K6-F1-N3160
5~95% (No Condensation)
-
Storage Humidity
K6-F1-N3160
5~95% (No Condensation)
